PF-60S-E Electric ceiling cranes pendant with double arms
PF-60S-E Electric ceiling cranes pendant with double arms the safety instructions:
The medical electric elevator tower protects the ground impedance
The protective grounding terminals of the equipment and all touching metal parts that have been protected to earth shall not exceed 0.1 ohms.
2, the medical bridge type electric elevator tower equipment has the leakage current
The normal state is not greater than 5mA, and the single failure state is not greater than 10mA
3, medical bridge electric elevator electrical dielectric strength
The power source portion of the network can be subjected to the normal wave ac voltage of 1500v. 50HZ for 1 minute dielectric strength test, no puncture or flashover phenomenon.
Part 4, network power supply and medical bridge type electric cranes is greater than 1 m Ω insulation between metal parts.
5, tailored to meet your personalized needs, to provide system solution for the hospital, according to the different needs of each customer and the actual situation, to design standardization in the operating room equipment configuration, the ICU work environment to carry on the design, the maximum to meet customer demand.
The tower size, gas box, equipment tray, drawer, and fluid connection can be combined flexibly. Product standardization production, equipment and accessories are universality.
Own installation, maintenance team, can meet the customer’s period limit in time. The product line is perfect, and our product line can produce hundreds of products from ordinary to high-end products that meet the needs of different levels of hospitals. Product line: hanging pillar, crane tower, suspension bridge three
Series.
The company has the professional design production team, the professional customer service team. Set up a one-on-one project team for customers to enjoy the pre-sale, pre-sale, and after-sales service.
Import quality, domestic price; Spend a light lift tower’s money to buy a heavy lift tower.
PF-60S-E Electric ceiling cranes pendant with double arms technical parameters:
| Model | PF-60S-E |
| Single-cantilever,1000mm+800mm,150kg | |
| Mechanical brake | |
| Funcctional column | |
| 38mm boom | |
| 2#Tray(490*400mm) Customized | |
| 2#Tray(490*400mm)+drawer | |
| stainless steel basket | |
| Gas outlet-German Standard Customized | |
| Narcotic AGSS outlet emission(jet/symphonic) | |
| Universal socket Customized | |
| Network communication interface socket RJ45 | |
| Cable tracheal folder | |
| Cas plug | |
| Apply to:Surgery,Anesthesia,Endoscopy | |
| Can be customized |
PF-60S-E Electric ceiling cranes pendant with double arms the reliability and stability:
From German classic design, high strength aluminum alloy, modular combination. Whole sealing, streamline, surface oxidation spray treatment, never rust
All air source terminals and tower hosts are both purveaux and German
The gas outlet can be used by German famous brand, MEDICOP, which is reliable for 10 years.
Electric socket can be used in France famous brand — -roger long, the quality is reliable, the assurance USES 10 years.
Each rotating joint of the tower device is equipped with double brake: mechanical brake + pneumatic brake device to ensure that the tower equipment is accurate and safe and reliable.
Each rotating joint is made of German famous brand, SKF, which is reliable for five years.
Electric elevating motor USES the German famous brand
Equipment pallet: high strength aluminum alloy whole drawing, with standard stainless steel rails
The tray is optional 450mmx400mmmx30mm. Adopt 10mm by 25mm international standard edge rail. The rounded corners are designed with a drawer and the tray can move up and down.
PF-60S-E Electric ceiling cranes pendant with double arms logistics:
 |
 |
